Ronstan RC1190-2.0 Series 19 Track Black 1996mm M5 CSK FH P:100mm SH:50mm

The Ronstan RC1190-2.0 Series 19 Track Black 1996mm M5 CSK
FH P:100mm SH:50mm is suitable for dinghy and catamaran
mainsheet traveller and jib lead sheeting systems, and mainsheet
systems on sportsboats and keel boats to 7m (23ft).

Ronstan RC1190-2.0 Series 19 Track Black 1996mm M5 CSK FH
P:100mm SH:50mm Specifications:

• Material: Alloy
• Track Fastenings: 5mm (3/16″), countersunk head fasteners at
  100mm (3.937″) centres
• Stopholes at 50mm (1.969″) centres
• Length: 1996 mm
• Width: 19.0 mm
• Weight: 620 g
• Minimum Curve Radium:
  • For 50mm (1 31/32″) car. Min horizontal ‘A’ curve radius =
    1500mm (59″). Min horizontal ‘B’ curve radius = 1500mm
    (59″).
  • For 57mm (2 1/4″) car. Min horizontal ‘A’ curve radius = 1500mm
    (59″). Min horizontal ‘B’ curve radius = 1500mm (59″).
  • For 70mm (2 3/4″) car. Min horizontal ‘A’ curve radius = 2500mm
    (99″). Min horizontal ‘B’ curve radius = 3000mm (118″).
  • For 85mm (3 11/32″) car. Min horizontal ‘A’ curve radius =
    3500mm (138″). Min horizontal ‘B’ curve radius = 4500mm
    (177″).
  • For 100mm (3 15/16″) car. Min horizontal ‘A’ curve radius =
    5000mm (197″). Min horizontal ‘B’ curve radius = 5500mm
    (217″).
  • For 148mm (5 27/32″) car. Min horizontal ‘A’ curve radius =
    11000mm (433″). Min horizontal ‘B’ curve radius = 15000mm (591″).
    Standard low profile track has stop holes to accept cars with
    plunger stops.
